The VX2000 Pro is an all-in-one controller combining video processing and video control functionalities into a single device. Equipped with 20 Ethernet ports, it supports three working modes
Description
The VX2000 Pro is an all-in-one controller combining video processing and video control functionalities into a single device. Equipped with 20 Ethernet ports, it supports three working modes: video controller, fiber converter, and ByPass. Capable of managing up to 13 million pixels, the VX2000 Pro can output at a maximum width of 16,384 pixels and a height of 8,192 pixels, making it perfectly suited for controlling ultra-wide and ultra-high LED screens on-site.
The VX2000 Pro boasts powerful video signal reception and processing capabilities, supporting a maximum resolution of 4K×2K@60Hz for video input. It can handle multiple video signal inputs and includes features like 12 layers, output scaling, low latency and pixel-level brightness and chroma calibration. These functions combine to deliver outstanding image display quality.
With various control options available, the VX2000 Pro can be operated via the front panel knob, NovaLCT, Unico and VICP app, providing you with a convenient and effortless control experience.
The VX2000 Pro is housed in an industrial-grade casing, which, combined with its powerful video processing and transmission capabilities, makes it robust and well-suited for complex operational environments. The VX2000 Pro is a perfect fit for medium and high-end rental, stage control systems and fine-pitch LED screens.
Features
Multiple connectors, free input and output
A comprehensive range of input connectors
Output connectors
Self-adaptive OPT 1/2 for either video input or sending card output
HDMI mosaic
Fiber input mosaic
Audio input and output
Free topology
Low latency
Output synchronization
EDID management
Diverse display possibilities for flexible configuration
Easy preset saving and loading
Multiple layer display
3D function
Personalized image scaling
Powerful video processing
Color adjustment
Pixel level brightness and chroma calibration
USB playback, timesaving and effortless
Supports USB playback for instant plug-and-play convenience.
Multiple device modes and operation modes, convenient and efficient
Three working modes
Multiple control options
Data saving after power failure and backup design, stable and reliable
End-to-End backup
Ethernet port backup test
Data saving after power failure
24/7 rigorous stability test under extreme high and low temperatures proved robust stability and reliability
Download Specification:
Novastar VX2000 Pro All-in-One Controller Specification
